Edimax RA21S User Manual

73
III-3-7-2. DMZ
A Demilitarized Zone (DMZ) is an isolated area in your local network where
private IP addresses are mapped to specified Internet IP addresses, allowing
unrestricted access to the private IP addresses but not to the wider local
network.
You can define a virtual DMZ host here. This is useful for example, if a
network client PC cannot run an application properly from behind an NAT
firewall, since it opens the client up to unrestricted two-way access.
Enable DMZ
Check/uncheck the box to enable/disable the
device’s DMZ function.
Public
Select “Dynamic IP” or “Static IP” here.
For “Dynamic IP” select an Internet connection
session from dropdown menu.
For “Static IP” enter the IP address that you
want to map to a specific private IP address.
Client PC
Enter the private IP address that the internet IP
address will be mapped to.
Add
Click
“
Add
”
to add the client to the
“
Current
