Edwards E2M275 Instruction Manual

© Edwards Limited 2008. All rights reserved. Page 9
Edwards and the Edwards logo are trademarks of Edwards Limited.
SYSTEM DATA
A652-18-880 Issue C
4SYSTEM DATA
4.1 Physical data
4.1.1 Dimensions
The figures shown in Table 2 are typical values of the overall length of the pump when fitted with a flameproof
motor. This is the only dimension that deviates from the standard product.
Note: Customers should be aware that there might be differences in dimensions, terminal box size and position
when sourcing replacement motors.
4.1.2 Mass
4.2 Mechanical data
Degree of protection IP55 (1 ph and 3 ph pumps)
Maximum tilt angle 10°
Motor rotational speed (50 Hz supply) 1430 rpm
Motor rotational speed (60 Hz supply) 1710 rpm
Table 2 - Overall length
RV3/5 RV8 RV12 E1M18 E2M18 E2M28
E1M/
E2M40
E1M/
E2M80
E1M/
E2M175
E1M/
E2M275
510 mm 550 mm 570 mm 526 mm 576 mm 606 mm 775 mm 840 mm 1010 mm 1110 mm
Table 3 - Pump mass
Pump type Mass with no oil (kg)
RV3 28.0
RV5 28.0
RV8 31.0
RV12 32.0
E1M18 37.0
E2M18 39.0
E2M28 42.0
E1M40 85.0
E1M80 101.8
E1M175 231.4
E1M275 262.4
