Edwards E2M275 Instruction Manual

A652-18-880 Issue C
Page 10 © Edwards Limited 2008. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
SYSTEM DATA
4.3 Operating conditions
Temperature range
Operating +12 °C to +40 °C (53 °F to 104 °F)
Relative humidity 10% to 90%
Maximum operating altitude 1000 m.
4.4 Noise data
Note: Data measured at ultimate vacuum 1 metre from end of the pump.
4.5 Vibration data
Refer to pump instruction manual.
4.6 Electrical data
4.6.1 Electrical data: single-phase pumps
When you start a cold pump, the motor will draw the start-up current shown in Table 5 for several seconds. A slow-
blow fuse is required to prevent fuse failure during pump start-up. Within five minutes, as the oil and pump warms
up, the current drawn will slowly reduce to the full load current specified in Table 5.
Table 4 - Noise data
Pump Variant dB (A)
RV3, 5, 8, 12 1 ph 230 V 50 Hz 48
E1M/E2M18 E2M28 1 ph 230 V 50 Hz 57
E1/E2M40 3 ph 400 V 50 Hz 72
E1/E2M80 3 ph 400 V 50 Hz 70
E1/E2M175 3 ph 400 V 60 Hz 75
E1/E2M275 3 ph 400 V 60 Hz 75
Table 5 - Electrical data (single-phase pumps)
Pump
Nominal
supply (V)
Frequency
(Hz)
Power
(kW)
Full load
current (A)
Start-up
current (A)
Recommended
fuse rating (A)
RV3, 5, 8, 12 230 50/60 0.55 5.6 22.5 10
E1M18, E2M18,
E2M28
230 50/60 0.75 6.4 24 10
