Edwards E2M28 User Manual

Figure 2 Single-phase motors: Dimensions mm (inches)
347 (13.66)
111 (4.37)
12 (0.47)
25 (0.98)
241 (9.49)
584 (22.99)
598 (23.54)
251 (9.88)
180 (7.09)
170 (6.69)
60 (2.36)
227 (8.94)
25 (0.98)
241 (9.49)
47 (1.85) 43 (1.69) 39 (1.54)
10 (0.39)
317 (12.48)12 (0.47)
Figure 3 Three-phase motors: Dimensions mm (Inches)
180 (7.09)
170 (6.69)
60 (2.36)
227 (8.94) 229(9.02)
25 (0.98)
25 (0.98)
241 (9.49)
47 (1.85) 43 (1.69)
39 (1.54)
10 (0.39)
317 (12.48)
12 (0.47)
553 (21.77)
Page 14
A37310880_V - Technical data

Edwards E2M28 Specifications

General

Type	Rotary Vane Pump
Inlet Connection	1 inch BSP
Inlet Port	1 inch BSP
Ultimate Vacuum (with gas ballast)	1 x 10-2 mbar
Motor Power	1.1 kW
