Edwards E2M28 User Manual

Pump item number Voltage (V) Frequency (Hz)
100-105
200
200-210
60
50
60
A37317984, A37325984 110
115-120
200-240
200-230
50
60
50
60
Motor output rang (connuous)
50 Hz operaon 0.75 kW
60 Hz operaon 0.90 kW
Table 7
Recommended cord sets for -984 pump variants and cable specicaons
Descripon Rang Coupler type Item number
Cord set assembly, UK
Cable style = H05VV-F, 3 x 1.5 mm
2
, 300 V,
70 °C, maximum length of 2.5 metres
Plug type = BS1363 UK plug
Straight entry A50505003
Appliance coupler = IEC60320 style C19
Fuse type = BS1363 10 Amp fuse, to an
IEC60320 style
Right angled
entry
A50505006
Cord set assembly,
Europe
Cable style = H05VV-F, 3 x 1.5 mm
2
, 300 V,
70 °C, maximum length of 2.5 metres
Straight entry A50506003
Plug type = European Schuko VDE
approved, 16 A 250 V rated with dual
earthing contact
Appliance coupler = IEC60320 style C19
Right angled
entry
A50506006
Cord set assembly,
USA/Canada (200 - 230
V)
Cable style = SJT, 3 x 14 AWG, 300 V,
90 °C, VW-1 maximum length of 3.0
metres
N/A
Plug type = NEMA, 6-15P plug
Appliance coupler = IEC60320 style C19
Page 16
A37310880_V - Technical data

Edwards E2M28 Specifications

General

Type	Rotary Vane Pump
Inlet Connection	1 inch BSP
Inlet Port	1 inch BSP
Ultimate Vacuum (with gas ballast)	1 x 10-2 mbar
Motor Power	1.1 kW
