Appendix A
A2.3 Electrical data: three-phase motors
The pumps are available with the three-phase motor specified in Table A1. The dual voltage motors can be manually
set-up to work with the nominal supplies of 220-240 V, 380-415 V, or 208-230 V (Refer to Section 3.7). Dual voltage
motors are supplied preset to the highest of the selectable voltages.
Table A1 - Elect rica l data (thr e e-ph ase m o tors )
Pump
Nominal
supply (V)
Frequency
(Hz)
Power (kW)
Full load
current (A)
Start-up
current (A)
Recom-
mended fuse
rating (A)*
Electrical
connection
Figure
E2M40S
208 50 1.5 6.8 41 25 5
208-230 60 1.5 6.5 39 25 5
460 60 1.5 3.1 18.6 15 6
E2M80S
208 50 3 12.4 71 40 5
208-230 60 3 11.8 71 40 5
460 60 3 5.6 34 20 6
* Yo u may ne e d to use a differen t f use ra t i n g. Use t h e information supplied with your circuit breaker or
starter to select the correct fuse rating.
