Edwards nXDS10i nXDS15i User Manual

A735-01-860 Issue A
Page 10 © Edwards Limited 2012. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Connection for serial control and monitoring
Fault history 2 ?V817
0..99999
64-bits
encoded as
four 16-bit
words:
<0000..FFFF>;
<0000..FFFF>;
<0000..FFFF>;
<0000..FFFF>
-
Decimal
Hexidecimal
Hours
-
Fault history at 2
nd
last trip:
nXDS pump-controller
powered time (hours)
system status register 01;
system status register 02;
warning register 01 and fault
register 01
*
Fault history 3 ?V818
0..99999
64-bits
encoded as
four 16-bit
words:
<0000..FFFF>;
<0000..FFFF>;
<0000..FFFF>;
<0000..FFFF>
-
Decimal
Hexidecimal
Hours
-
Fault history at 3
rd
last trip:
nXDS pump-controller
powered time (hours)
system status register 01;
system status register 02;
warning register 01 and fault
register 01
*
Fault history 4 ?V819
0..99999
64-bits
encoded as
four 16-bit
words:
<0000..FFFF>;
<0000..FFFF>;
<0000..FFFF>;
<0000..FFFF>
-
Decimal
Hexidecimal
Hours
-
Fault history at 4
th
last trip:
nXDS pump-controller
powered time (hours)
system status register 01;
system status register 02;
warning register 01 and fault
register 01
*
Customer
interface
software version
?S820 [1..11] - String
ASCII
Characters
Customer interface software
version number (Dxxxxxxxx Y)
(where Dxxxxxxxx is the
drawing number and Y is the
revision)
Factory
settings
!C821 1 - Decimal -
Reset all configuration
options and parameters to
factory settings
Motor-control
boot-loader
version
?S822 [1..11] - String
ASCII
Characters
Motor-control boot-loader
version number
(Dxxxxxxxx Y)
(where Dxxxxxxxx is the
drawing number and Y is the
revision)
Customer
interface
boot-loader
version
?S823 1..11] - String
ASCII
Characters
Customer interface boot-
loader version number
(Dxxxxxxxx Y)
(where Dxxxxxxxx is the
drawing number and
Y is the revision)
Table 3 - Summary of the commands that can be sent to the nXDS pump (continued)
Object name Command
Parameter
range
Factory
setting
Data type Units Comments
