A735-01-860 Issue A

Edwards and the Edwards logo are trademarks of Edwards Limited.

Connection for serial control and monitoring

8Reserved-

9Reserved-

10 Reserved -

11 Reserved -

12 Reserved -

13 Reserved -

14 Reserved -

15 (msb) Reserved -

Table 9 - Warning register 2 flags

Bit Status Flag Active Flat Meas

0 (lsb) Reserved -

1 Low pump-controller

temperature

Pump-controller temperature is below the minimum measurable

value

2Reserved-

3Reserved-

4Reserved-

5Reserved-

6 Pump-controller temperature

regulator active

Output current is being restricted due to high pump-controller

temperature

7Reserved-

8Reserved-

9Reserved-

10 High pump-controller

temperature

Pump-controller temperature is above the maximum measurable

value

11 Reserved -

12 Reserved -

13 Reserved -

14 Reserved -

15 (msb) Self test warning Non-critical problem with EEPROM or other internal function

Table 8 - System status register 2 flags (continued)

Bit Status Flag Active Flat Meas
