Edwards nXDS10i nXDS15i User Manual

A735-01-860 Issue A
Page 20 © Edwards Limited 2012. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Connection for serial control and monitoring
Table 11 - Service flags
Bit number Status flag Active flag means
0 Tip seal service due Set when hours until tip seal service due = 0
1 Bearing service due Set when hours until bearing service due = 0
2Reserved -
3 Controller service due Set when hours until controller service due = 0
4Reserved -
5Reserved -
6Reserved -
7 Service due Service is due. Specific operation required should be
determined by checking the bits above
8 - 15 Reserved -

Edwards nXDS10i nXDS15i Specifications

General

Pump Type	Dry Scroll Pump
Pumping Speed	10 m³/h (nXDS10i), 15 m³/h (nXDS15i)
Motor Type	Brushless DC
Operating Temperature	+5 to +40 °C
Voltage	100-240 VAC, 50/60 Hz
Weight	15 kg
