HIGH THROUGHPUT MODE S
Parameter Units
RV8 RV12
1-phase 3-phase 1-phase 3-phase
Gas-ballast ow
l min
-1
16 16
Maximum water vapour pump-
ing rate
kg h
-1
0.22 0.20 0.29 0.25
Maximum water vapour inlet
pressure
mbar 38 34 32 28
Pa
3.8 x 10
3
3.4 x 10
3
3.2 x 10
3
2.8 x 10
3
Table 7
Performance characteriscs
MODE SE-
LECTOR
POSITION
GAS BALLAST CONTROL
Closed (posion ‘0’) Low ow (posion ‘I’) High ow (posion ‘II’)
High Vac-
uum mode
S
Ulmate total pressure Ulmate total pressure Ulmate total pressure
mbar Pa mbar Pa mbar Pa
2 x 10
-3
2 x 10
-1
3 x 10
-2
3
1.2 x 10
-1
(RV3)
1.0 x 10
-1
(RV5)
6 x 10
-2
(RV8/12)
1.2 x 10
1
(RV3)
1.0 x 10
1
(RV5)
6.0 (RV8/12)
Use for the best ulmate
pressure
Maximum water vapour
pumping rate
Maximum water vapour pump-
ing rate
1-phase
pumps
3-phase
pumps
1-phase pumps 3-phase pumps
0.06 kg h
-1
0.04 kg h
-1
0.22 kg h
-1
(RV3/5/8)
0.29 kg h
-1
(RV12)
0.12 kg h
-1
(RV3/5)
0.20 kg h
-1
(RV8)
0.25 kg h
-1
(RV12)
03/2021 - ©Edwards Limited
Page 17A65201880_AA
A65201880_AA - Technical data
