Edwards RV5

Figure 10 Accessories
1 2 3 4
5
6 7 8
9
10
12
11
CS/1105/A
1. Inlet catchpot 2. Inlet dust lter
3. Inlet desiccant trap 4. Inlet chemical trap
5. Solenoid operated gas-ballast valve 6. Foreline trap
7. Solenoid operated pipeline valve 8. Outlet mist lter
9. Gas-ballast adaptor 10. Gravity oil drain kit
11. Vibraon isolators 12. Oil drain-extension
1. Inlet catchpot 2. Inlet dust lter
3. Inlet desiccant trap 4. Inlet chemical trap
5. Solenoid operated gas-ballast valve 6. Foreline trap
7. Solenoid operated pipeline valve 8. Outlet mist lter
9. Gas-ballast adaptor 10. Gravity oil drain kit
11. Vibraon isolators 12. Oil drain-extension
