Appendix D: Smart Encoder Command List
Local Entry Modes
Regeneration Mode:
Regenerate Upstream VANC <CTRL+A>! [ON/OFF] <ENTER>
Ignore Upstream L21 Channel <CTRL+A>6 Channel <ENTER>
Return Upstream L21 Channel <CTRL+A>7 Channel <ENTER>
Begin PassThru Mode <CTRL+A>3 [Pairing] [Field] <ENTER>
End PassThru Mode <CTRL+C>
Begin RealTime Mode <CTRL+A>2 [Channel] [Rollup] [bBase]
<ENTER>
End RealTime Mode <CTRL+C>
HD Output Types
HD VANC Insertion:
VANC Insertion Disabled <CTRL+A># OFF <ENTER>
VANC Insertion Enabled <CTRL+A># ON <ENTER>
VANC Line Change <CTRL+A>f 334 [Line] <ENTER>
VANC No 333 Detection <CTRL+A>f vanc [Line] <ENTER>
333 Serial Output:
333 Output Manual configure <CTRL+A>f 333 <ENTER>.
GA Serial Output:
GA Serial Output <CTRL+A>f ga <ENTER>.
XDS Insertion
XDS Entry:
Enable XDS Entry <CTRL+A>O XDS O <ENTER>
Load XDS Packet <CTRL+A>P Packet Duration Content
[Priority] <ENTER>
Sample XDS entries <CTRL+A>P 103 –1 {Evening News}
<ENTER>
<CTRL+A>P 105 00.30.00 4844 <ENTER>
XDS Packet:
Load Default XDS Packet <CTRL+A>P LPacket Duration Content
[Holdoff] <ENTER>
Sample XDS entries <CTRL+A>P L105 –1 4840 <ENTER>
Load NVM XDS packet <CTRL+A>w <CTRL+A>P Packet -1
Content <ENTER>
Report XDS Queue <CTRL+A>e [Packet] <ENTER>
Delete XDS Packet <CTRL+A>P Packet <ENTER>
Block Upstream XDS <CTRL+A>T -Class00 <ENTER>
End Blocking <CTRL+A>T Class00 <ENTER>
End Blocking Example <CTRL+A>T –0100 <ENTER>
