BIPOLAR CONNECTOR
The eego amplifier has one bipolar input connectors, BIPOLAR IN. The 50-pin high-density, high-
quality connectors give access to the 24 bipolar inputs and the patient ground. The patient ground is
identical to the referential channel patient ground. Only one patient ground connection should be
established and used when preparing a subject. Pin 50 on the connector is unused and reserved for
internal use.
eego amplifier BIPOLAR IN connector
Channel
Number
Pin numbers, 50-pin
high-density connector
negative
positive
BIP 1
1
26
BIP 2
2
27
BIP 3
3
28
BIP 4
4
29
BIP5
5
30
BIP 6
6
31
BIP 7
7
32
BIP 8
8
33
BIP 9
9
34
BIP 10
10
35
BIP 11
11
36
BIP 12
12
37
BIP 13
13
38
BIP 14
14
39
BIP 15
15
40
BIP 16
16
41
BIP 17
17
42
BIP 18
18
43
BIP 19
19
44
BIP 20
20
45
BIP 21
21
46
BIP 22
22
47
BIP 23
23
48
BIP 24
24
49
GND
25
