TRIGGER CONNECTOR
The eego amplifier provides an 8-bit trigger input via the 36-pin high-density connector at the
amplifier backside. The trigger connector is compatible with the XS-230 trigger adapter, which should
be used whenever connecting the amplifier with a trigger source (TTL).
WARNING: The trigger source must be compliant with IEC 60950.
eego amplifier trigger connector (and pinning for XS-230)
Pin numbers, 36-pin high-
density connector
Pin numbers, 25-pin DSUB
connector (XS-230)
Description
1
-
(not connected)
2
-
(not connected)
3
-
(not connected)
4
-
(not connected)
5
-
(not connected)
6
2
TTL Bit 1
7
3
TTL Bit 2
8
4
TTL Bit 3
9
5
TTL Bit 4
10
6
TTL Bit 5
11
7
TTL Bit 6
12
8
TTL Bit 7
13
9
TTL Bit 8
14
-
(not connected)
15
-
(not connected)
16
-
(not connected)
17
-
(not connected)
18
-
(not connected)
19
-
(not connected)
20
-
(not connected)
21
-
(not connected)
22
-
(not connected)
23
-
(not connected)
24
25
Trigger Ground
25
25
Trigger Ground
26
25
Trigger Ground
27
25
Trigger Ground
28
25
Trigger Ground
29
25
Trigger Ground
30
25
Trigger Ground
31
25
Trigger Ground
32
-
(not connected)
33
-
(not connected)
34
-
(not connected)
35
-
(not connected)
36
-
(not connected)
