eego EE-225 - Appendix B: Amplifier Technical Specifications (Emc)

eego amplifier EE-21x EE-22x User Manual
Rev. 5, DRN-PDO-1664 21 of 26 2016-07-11
APPENDIX B: AMPLIFIER TECHNICAL SPECIFICATIONS (EMC)
The compliance in the tables below is valid for eego amplifier with following accessories:
Part
Cable length (m)
Power supply XP Power Model AFM45US12C2
1.9
USB cable
1.8
XS-230 trigger adapter DB25
0.3
CA-2xx waveguard caps (tests below performed with CA-200)
1.2
XS-260 adapter for 16 bipolar channels (connection equivalent
to a set of 32 unipolar EEG inputs)
0.8
Guidance and manufacturer’s declaration – electromagnetic emissions
The eego amplifier is intended for use in the electromagnetic environment specified below. The customer and/or user of the
eego amplifier should ensure that it is used in such an environment.
Emission Test Compliance
Compliance
Electromagnetic Environment - guidance
RF Emissions CISPR 11
Group 1
The eego amplifier uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are
not likely to cause any interference in nearby electronic
equipment.
RF Emissions CISPR 11
Class B
The eego amplifier is suitable for use in all establishments,
including domestic and those directly connected to the
public low-voltage power supply network that supplies
buildings used for domestic purposes.
Harmonic Emissions
IEC 61000-3-2
Not applicable
Voltage Fluctuations/ Flicker
Emissions
IEC 61000-3-3
Not applicable
Guidance and manufacturer’s declaration – electromagnetic immunity
The eego amplifier is intended for use in the electromagnetic environment specified below. The customer and/or user of the
eego amplifier should ensure that it is used in such an environment.
Immunity Test
IEC 60601 test level
Compliance level
Electromagnetic Environment - guidance
Electrostatic discharge (ESD)
IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete, or ceramic tile. If
floors are covered with synthetic material, the
relative humidity should be at least 30 %.
Electrical fast
transient/burst
IEC 61000-4-4
± 2 kV for power supply
lines
± 1 kV for input/output
lines
± 2 kV for power supply
lines
± 1 kV for input/output
lines
Mains power quality should be that of a typical
commercial or hospital environment.
Surge
IEC 61000-4-5
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short
interruptions and voltage
variations on power supply
input lines
IEC 61000-4-11
<5 % U
T
(>95 % dip in U
T
)
for 0,5 cycle
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
<5 % U
T
(>95 % dip in U
T
)
for 5 s
<5 % U
T
(>95 % dip in U
T
)
for 0,5 cycle
40 % U
T
(60 % dip in U
T
)
for 5 cycles
70 % U
T
(30 % dip in U
T
)
for 25 cycles
<5 % U
T
(>95 % dip in U
T
)
for 5 s
Mains power quality should be that of a typical
commercial or hospital environment.
Power frequency
(50/60 Hz) magnetic field
IEC 61000-4-8
3 A/m
3 A/m
Power frequency magnetic fields should be at
levels characteristic of a typical location in a typical
commercial or hospital environment.
NOTE U
T
is the a.c. mains voltage prior to application of the test level.
