Repair Parts (continued)
Model Number
Element
Number
Assembly
Flow Meter
Assembly
(inc board)
Master
Display
Board
Transformer
Inlet & Outlet
Thermistors
SSR
ECO
Assembly
Contactor
Inlet
Manifold Kit
Outlet
Manifold Kit
Inlet Fitting
Flow Meter
Kit
XTP018208 EX05502-00 EX76042-02 EX09100-01 EX08303-07
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08309-02 EX78016-00 EX78017-00 EX78018-00
XTP024208 EX05502-01 EX76042-02 EX09100-01 EX08303-07
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08100-11 EX78016-00 EX78017-00 EX78018-00
XTP032208 EX05502-02 EX76042-02 EX09100-01 EX08303-07
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08100-10 EX78016-00 EX78017-00 EX78018-00
XTP016480 EX05502-03 EX76042-02 EX09100-01 EX08303-08
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08309-02 EX78016-00 EX78017-00 EX78018-00
XTP020480 EX05502-04 EX76042-02 EX09100-01 EX08303-08
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08309-02 EX78016-00 EX78017-00 EX78018-00
XTP024480 EX05502-05 EX76042-02 EX09100-01 EX08303-08
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08309-02 EX78016-00 EX78017-00 EX78018-00
XTP027480 EX05502-06 EX76042-02 EX09100-01 EX08303-08
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08309-02 EX78016-00 EX78017-00 EX78018-00
XTP036480 EX05502-07 EX76042-02 EX09100-01 EX08303-08
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08309-02 EX78016-00 EX78017-00 EX78018-00
XTP048480 HA-P004 EX76042-02 EX09100-01 EX08303-08
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08306-00 EX78016-00 EX78017-00 EX78018-00
XTP054480 HA-P005 EX76042-02 EX09100-01 EX08303-08
EX08200-16 &
EX08200-17
EX08200-12 EX279D EX08306-00 EX78016-00 EX78017-00 EX78018-00
