EemaX XTP PRO Series - Repair Parts Identification

37
REPAIRS
Repair Parts
WARNING
Service and repairs are to be performed by licensed electricians or qualified
servicemen.
WARNING
Before attempting any repairs to the heater, make sure that the electrical breaker is
“off” and confirm that there is no voltage at the heater.
p
* HEATING ELEMENT ASSEMBLY CONSISTS OF ONE HEATER CORE AND WIRE ELEMENT(S)
** FLOW METER KIT CONSISTS OF PADDLE WHEEL, DOWEL PIN, O RING AND 4 MOUNTING SCREWS.
ECO’s
Electrical Connections
LED Display &
Control Board
Current
Sensor
Contactor
Heating Element
Assembly*
Flow
Meter **
SSR’s
