7
GENERAL REQUIREMENTS
For initial conguration and all subsequent changes you will need:
1. Android smartphone or tablet with OS version 4.2 Jelly Bean or greater.
2. FieldBee application. You can install it from Google Play Store, follow the link or
simply search «FieldBee».
https://goo.gl/yL9hGf
3. FieldBee antenna.
4. RTK Bee Station (if applicable).
5. Registration with the local RTK correction signal provider (if applicable)
It is recommended to charge a battery to at least 20% before changing
congurations. Refer to the Charging section.
CONFIGURATION
REAR PANEL DIAGRAM BOTTOM ELEMENTS
1. Antenna socket
915/868 Mhz
2. Power & data socket
3. PowerOn
4. Led Indicator
5. Washer for
mounting on tripod
6. Holes for xing
on a metal plate
7. Magnets for mounting
on metal plates
8. Battery compartment
1
2
3
5
8
6
7
