EFOY 80 User Manual

Design and specifications
Page 53
2.3.3 General specifications of the EFOY fuel cell
EFOY 80
EFOY 150
EFOY Pro
900
EFOY Pro
1800
EFOY Pro
2800
Nominal voltage Lead: 12 V/24 V (lead gel, lead acid or AGM)
LiFePO4: 12.8 V/25.6 V
Permissible battery types
Lead: 2 V cells: 6S (12 V) and 12S (24 V)
LiFePO4: 3.2 V cells: 4S (12.8 V) and 8S (25.6 V)
Consumption
4
0.9 l/kwh
Number of fuel cartridges
1 (up to 8 with EFOY Fuel Manager)
Length of fuel cartridge
connection
75 cm
Weight
6.5 kg
6.9 kg
6.5 kg
7.2 kg
7.8 kg
Dimensions (L x W x H)
448 x 198 x 275 mm
Operation At the device, using the EFOY app, using the operating
panel or via the EFOY cloud
Data interface RJ-12 port (CAN & RS232) for the use of accessories
RJ-45 port (Ethernet)
Communication protocol
MODBUS TCP; plain text (SIO commands)
Electrical interface 4-pin port for EFOY charging cable
Power: plus (+) and minus (-): 4 mm²
Sensors: plus (+) and minus (-): 0.75 mm²
Electrical interface for
EFOY accessories
2-pin port: plus (+) and minus (-): min. 0.75 mm²/max.
2.5 mm²
Available voltage: battery voltage, max. current 2 A
Sound pressure level
5
at
1 m
< 44 dB
(A)
< 47 dB
(A)
< 45 dB
(A)
< 48 dB
(A)
< 50 dB
(A)
Installation space (L x W x
H)
510 x 320 x 290 mm
Incline along longitudinal
axis
Continual: 35°
Incline along lateral axis
Continual: 35°
Operating temperature
6
EFOY: -20 °C to +40 °C/EFOY Pro: -20 °C to +50 °C
Start temperature
EFOY: +3 °C to +40 °C/EFOY Pro: +3 °C to +50 °C
Storage temperature
+1 °C to +50 °C

EFOY 80 Specifications

General

Technology	Direct Methanol Fuel Cell (DMFC)
Fuel	Methanol
Nominal voltage	12 V
Operating voltage	10.5 V - 15 V
Operating temperature	+40 °C
