Maintaining and caring for the EFOY fuel cell
Page 68
If the fuel cartridge is inserted incorrectly, methanol can leak out.
If the M28 fuel cartridge is used in a horizontal position, the safety valve
and fuel cartridge connector must always be on the top side of the fuel
cartridge when lying on it’s side.
5.1.4 Connecting the MT60 methanol tank
The MT60 is not suitable for use in vehicles.
Remove the sealing cap.
Screw the fuel cartridge connection
onto the EFOY methanol tank.
MT60 tank:
The MT60 tank must be installed and
secured upright in stationary and mobile
applications.
Installation must be inspected and
approved for safety.
5.2 Cleaning the EFOY fuel cell
Risk of injury from electric shock.
Do not allow moisture to penetrate the EFOY fuel cell.
Switch off the EFOY fuel cell (see SECTION 4.2.4).
Unplug the charging cable (see SECTION 7.1).
Slightly moisten a soft cloth with a mild cleaning agent.
Clean the EFOY fuel cell with the cloth.
Reconnect the charging cable.
