EG4 BrightMount Adjustable Cat1 - Engineering Drawings

5
5. ENGINEERING DRAWINGS
179.5 in. (4560 mm)
89.8 in. (2280 mm)
43.3 in. (1100 mm)
51.2 in. (1300 mm)
51.2 in. (1300 mm)
51.2 in. (1300 mm)
33.5 in. (850
mm)
19.7 in.
(500 mm)
1.9 in.
(50 mm)
15.7 in.
(400 mm)
(330 mm)
(330 mm)
12.9 in.
12.9 in.
19.6 in.
498 mm
18.5 in.
470 mm
384 mm
15.1 in.
10.8 in.
274 mm
168 mm
67 mm
6.6 in
2.6 in.
