3.4 Hydraulic system
Hydraulic oil:
Check the hydraulic oil level only when the oil is cold.
The oil must be visible in the sight glass.
Top up if the oil is not visible in the sight glass.
Warning!
CClleeaann tthhee aarreeaa aarroouunndd tthhee ffiilllleerr bbeeffoorree
rreemmoovviinngg tthhee ffiilllleerr ccaapp ttoo mmaakkee ssuurree
tthhaatt nnoo ddiirrtt eenntteerrss tthhee hhyyddrraauulliicc ssyysstteemm,,
wwhheerree iitt mmaayy ccaauussee ddaammaaggee..
Top up hydraulic oil
A) Park the Egholm 2100 on level ground.
B) Turn off the engine.
C) Remove the filler cap and add Texaco Rando HDZ
46 oil.
D) Replace the filler cap and start the engine.
E) Check that the oil covers ¾ of the sight glass.
Tank filter
Replace the filter and clean the filter housing at every
service inspection.
Hydraulic oil
Adding oil
Tank filter
Tank filter housing
21
3. SERVICE AND MAINTENANCE
