56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX450012
◾ When clearing jammed material or servicing the
machine, make sure the switch is off and the
battery pack is removed. Unexpected starting
of the machine while clearing jammed material or
servicing may result in serious personal injury.
◾ When transporting or storing the machine, always
fit the cover on metal blades. Proper handling of
the machine will reduce the likelihood of accidental
contact with the blade.
◾ Damage to Trimmer - If you strike a foreign object
with the trimmer or it becomes entangled, stop the
machine immediately, check for damage and have any
damage repaired before further operation is attempted.
Do not operate with a broken guard or spool.
◾ If the equipment should start to vibrate abnormally,
stop the motor and check immediately for the
cause. Vibration is generally a warning of trouble. A
loose head may vibrate, crack, break or come off the
trimmer, which may result in serious or fatal injury.
Make sure that the cutting attachment is properly fixed
in position. If the head loosens after fixing it in position,
replace it immediately. Never use a trimmer with a
loose cutting attachment.
◾ Use only with the battery packs and chargers listed
below:
BATTERY PACK CHARGER
BA1400, BA1400T, BA2800,
BA2800T, BA4200, BA4200T,
BA5600T, BA6720T
CH2100E, CH5500E,
CH7000E
BAX1501 CHX5500
Blade thrust causes and related warnings
Blade thrust is a sudden sideways, forward or backward
motion of the machine, which may occur when the blade
jams or catches on an object such as a sapling or a tree
stump. It can be violent enough to cause the machine and/
or operator to be propelled in any direction, and possibly
lose control of the machine.
Blade thrust and its related hazards can be avoided by
taking proper precautions as given below.
◾ Maintain a firm grip with both hands on the
machine and position your arms to resist blade
thrust. Position your body to the left side of the
machine. Blade thrust can increase the risk of injury
due to the machine moving unexpectedly. Blade thrust
can be controlled by the operator if proper precautions
are taken.
◾ If the blade binds, or when interrupting a cut
for any reason, switch the machine off and hold
the machine motionless in the material until the
blade comes to a complete stop. While the blade
is binding, never attempt to remove the machine
from the material or pull the machine backward
while the blade is in motion, otherwise blade thrust
may occur. Investigate and take corrective actions to
eliminate the cause of blade binding.
◾ Do not use blunt or damaged blades. Blunt or
damaged blades increase the risk of jamming or
catching on an object, resulting in blade thrust.
◾ Always maintain good visibility of the material
being cut. Blade thrust is more likely to occur in areas
where it is difficult to see the material being cut.
◾ If you are approached by another person while
operating the machine, switch the machine off.
There is an increased risk of injury to other persons
being struck by the moving blade in the event of blade
thrust.
SAVE THESE INSTRUCTIONS!
SPECIFICATIONS
Voltage
56 V
n
0
1: 3500 /min
2: 4500 /min
3: 5200 /min
Cutting Mechanism 3-tooth metal blade
Cutting Swath 30 cm
Ingress Protection Rating
IPX5* (Protection from
water jets)
Recommended Operating
Temperature
0 – 40 °C
Recommended Storage
Temperature
-20 – 70 °C
Weight (without battery pack) 5.4 kg
* NOTE: IPX5 rating is based on the machine and battery
being used together as a system.
Recommended Accessories
PART NAME MODEL NUMBER
Brushcutter blade ABB1203-2
