56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX450014
3. Rotate the motor shaft to align the slot in the inner
flange with the shaft-lock access hole in the gear
case (Fig. D3).
4. Insert the included hex key into the aligned holes to
act as shaft lock (Fig. D4).
5. Mount the blade onto the motor shaft, ensuring that
the surface of the blade is flush with the surface
of the inner flange bulge. Mount the outer flange
and the nut (Fig. D5). Finger-tighten the nut in
COUNTERCLOCKWISE direction.
6. Position the gear case against a solid surface for
support. With one handgrasping the blade and using
the other hand to grasp the multi-function wrench to
tighten the nut following the directional arrow icon
marked on the outer flange (Fig. D6).
ATTACHING/DETACHING BATTERY
NOTE:
Fully charge battery pack before first use.
To Attach
Align the battery ribs with the mounting slots in the
machine’s battery port and slide the battery pack until it
snaps into position (Fig. E1).
To Detach
Always be aware of the location of your feet, children, or
pets when pressing the battery-release button. Serious
injury could result if the battery pack falls.
NEVER remove the battery pack at a high location.
1. Depress the battery-released button and the battery
pack will disengage from the latch (Fig. E2).
2. Grasp the battery pack and remove it from the
machine.
MOUNTING THE DOUBLE-SHOULDER STRAP
1. Put the double-shoulder strap on your body and insert
the two parts of the strap buckle into each other until a
click is heard (Fig.F1).
2. Insert the carabiner hook of the hip pad into the hole
of the shoulder strap loop fixed on the shaft, and press
the shaft down softly (Fig.F2 & F3 & F4).
3. Hold the brushcutter with both hands on the right side
of your body (Fig. F5). The blade should be parallel to
the ground at a proper cutting distance without the
need for the operator to bend over.
4. Releasing the brushcutter can be achieved in two
ways: release the strap buckle (Fig. F6) or press the
carabiner of the strap and remove the hook from the
loop fixed on the shaft (Fig. F2).
WARNING: When an emergency occurs, take it off
from your shoulder immediately, no matter what way the
strap is in. Releasing the strap buckle (Fig.F6) and both
hands taking off your shoulders at each side is a quick
release method.
WARNING: You should not use the single-shoulder
strap and double-shoulder strap simultaneously.
NOTICE: When wearing the strap, no other wearable
interferes with the release and removal of the strap.
OPERATION
WARNING: Do not allow familiarity with this product
to make you careless.
Remember that a careless fraction of a second is
sufficient to inflict serious injury.
WARNING: Always wear eye protection along with
hearing protection. Failure to do so could result in objects
being thrown into your eyes and other possible serious
injuries.
WARNING: Do not use any attachments or
accessories not recommended by the manufacturer of
this product. The use of attachments or accessories not
recommended can result in serious personal injury.
WARNING: To prevent serious personal injury,
remove the battery back from the machine before
servicing, cleaning, changing attachments or removing
material from the unit.
APPLICATIONS
You may use this product for the purpose listed below:
◾ With 3-tooth metal blade (original configuration):
Cutting grass, weeds, wild growth, and scrub, thinning
young stands with a maximum stem diameter of 2 cm.
◾ With trimmer Head (sold separately): Trimming grass
and weeds from around porches, fences, and decks.
NOTICE: The machine is to be used only for its
prescribed purpose. Any other use is deemed to be a case
of misuse.
HOLDING THE BRUSHCUTTER (Fig.G)
WARNING: Dress properly to reduce the risk of
injury when operating this machine. Do not wear loose
clothing or jewelry. Wear eye and ear/hearing protectors.
Wear heavy, long pants, boots and gloves. Do not wear
short pants or sandals or go barefoot.
