56 VOLT LITHIUM-ION COMMERCIAL BRUSHCUTTER — BCX4500
13
PACKING LIST
PART NAME QUANTITY
Brushcutter 1
Blade and Blade Sheath Set 1
Guard 1
Double-shoulder Strap 1
Hex Key (4 mm) 1
Multi-function Wrench 1
Operator’s Manual 1
DESCRIPTION
KNOW YOUR BRUSHCUTTER (Fig. A)
WARNING: Never operate the machine without the
guard firmly in place. The guard must always be on the
machine to protect the user.
WARNING: When the tool is equipped with a trimmer
head, the guard accessory with line–cutting blade should
be mounted onto the guard. Failure to comply will result in
overly long cutting line and overload the motor. Never use
the trimmer head without guard accessory.
ASSEMBLY
WARNING: If any parts are damaged or missing,
do not operate this product until the parts are
replaced. Use of this product with damaged or missing
parts could result in serious personal injury.
WARNING: Do not attempt to modify this product
or create accessories not recommended for use
with this product. Any such alteration or modification is
misuse and could result in a hazardous condition leading
to possible serious personal injury.
WARNING: Always wear heavy gloves when
performing any maintenance on the blade. Be careful
of the blade and protect your hands from being injured by
the blade.
WARNING: To prevent accidental starting that
could cause serious personal injury, always remove
the battery pack from the machine when assembling
parts, making adjustments, cleaning, or when not in
use.
ADJUSTING THE BIKE HANDLE
WARNING: Always remove the battery pack from
the product when you are assembling parts, making
adjustments, cleaning, or when the product is not in use.
1. During shipping, the bike handle is mounted on the
shaft as shown in Fig.B1
2. Loosen the wing bolt on the bracket and then lift the
bike handle 180° around the shaft as shown in Fig.
B2.
3. Turn the handle 90° COUNTERCLOCKWISE to make
it face the cutter (Fig. B3).
4. Tighten the wing bolt to secure the bike handle in
place.
WARNING: Risk of serious personal injury.
Only start the tool when the bike handle is adjusted
perpendicular to the pole and the operator holds it
with both hands.
MOUNTING THE GUARD
WARNING: To reduce the risk of injury to people, do
not operate without guard in place.
1. Loosen the two bolts in the guard with the supplied
hex key, then remove the bolts and spring washers
from the guard (Fig.C1)
2. Lift the cutter head and face it downward. Align
the two mounting holes in the guard with the two
assembly holes in the base of the shaft and then
secure the guard onto the shaft base with the two
screws and two spring washers (Fig.C2).
NOTICE: There are two kinds of guards compatible with
this machine. The guard with icon can only be
used with the string trimmer head and must not be used
with brusher cutter head. Be careful to choose the correct
guard when using the machine.
NOTICE: The string trimmer guard is not included (EGO
AD4500, sold separately).
MOUNTING THE BLADE
1. The blade is shipped with a sheath. Before mounting
the blade onto the brushcutter, the sheath should be
removed by undoing the clamp wire from the loop on
the sheath (Fig. D1).
2. Familiarize yourself the cutting head assembly shown
in Fig. D2. Before mounting the blade, make sure that
the inner flange and the flange cover are positioned
correctly on the motor shaft (Fig.D2).
