27
15. Fix the lock-off button into the mounting hole in the handle.
16. Fix the trigger in the handle.
Description Part Number
Switch Trigger 3127496000
Lock off Button 3127495000
Spring 3660427000
Lock-off button
Trigger
Assemble the Product
