12. Move the oil tank to the position as the figure shown below.
13. Mount the fan baffle to the motor and lock it with 4 screws.
Description
Part Number
Quantity
Tapping Screw
5610042014
4
Fan Baffle
3127502001
1
Fan baffle
Assemble the Product
Oil Tank
Assembly
