28
17. Close the housing and lock it with 12 tapping screws.
18. Mount the front handle to the housings and lock it with 4 tapping screws.
19. Connect the oil tank cover with the hook line and tighten it.
Description
Part Number
Qty.
Tapping screw
5610042014
12
Assemble the Product
Close the housing
Mount the front handle
