4. Loosen the oil tank and disconnect the hook line with the oil tank cover.
5. Loosen the 12 screws in housing to open the housing.
Description
Part Number
Quantity
Tapping Screw
5610042014
12
Disassemble the Product
9
Loosen
Oil Tank Cover Hook Line
Pull
