6. Place the spring onto the actuator and make sure it is securely located(Fig. 1).
7. Close the switch box cover as steps in following “Close the Switch Box Cover” part show.
10
NOTICE: In case the spring remains located in the bottom switch box cover after opening the
switch box cover(Fig. 2), remove it initially.
2
Bottom Switch Box Cover
2. The Safety Button Replacement
1
LM2120E-SP Lawn Mower
