When opening the left/right beam housing, the following parts can be replaced:
Description Part Number
Micro switch 4870500001
Left beam housing set 2824427001
Right beam housing set 2824426001
Switch actuator 3126768001
Spring 3660287002
Left inner tube ASSY 2824292001
Right inner tube ASSY 2824295001
Beam tube 3705393001
3
Left beam housing set
Right beam housing set
(micro switch inside)
Right inner
tube ASSY
Beam tube
Left inner tube ASSY
Left/Right Beam Housing Replacement
LM2120E-SP Lawn Mower
