5. To Replace the Top & Bottom Switch Box Cover
1. Remove all the switches as well as their cables from the top switch box cover;
2. Remove the main switch lever and self-propelled lever from the top switch box cover;
3. Replace with a set of new covers;
4. Refer to the previous slides to fix the parts into the top switch box cover.
Description Part Number
Top & Bottom switch box set
2824305001
15
LM2120E-SP Lawn Mower
