1. Release switches and remove the battery pack from the mower.
2. Wear protective gloves, turn the mower on its side (Fig. 1).
3. Place a metal rod (e.g., a screwdriver) with a diameter between 9 - 11mm into the fixing hole to
act as a stabilizer and place another metal rod (e.g., a long bit) with a diameter between 5 -
6.35mm into the holes to act as another stabilizer (Fig. 2).
1. Blade Removal
3
1
Fixing hole
Another
Stabilizer
Stabilizer
2
LM2120E-SP Lawn Mower
