EGO LM2120E-SP User Manual

4. Put the spring into the hole. Mount the main switch set onto the spring with the hook outside the
spring(Fig. 1).
5. Align the clamp slot with the locating rib on the housing(Fig. 2).
6. Lock the main switch set by tightening the
clamp with the 2 screws(Fig. 3) .
13
Clamp Slot
Locating Rib
2
3
ALIGNING
3. The Main Switch Set(Lever/Trigger) Replacement
1
Spring
Hook out of
the spring
LM2120E-SP Lawn Mower
