56-VOLT LITHIUM-ION ELECTRIC ZERO TURN MOWER — ZT5200L/ZT5200L-FC20
Auto-Parking Icon
When the mower stops driving on a slope if the operator has opened the lap bars and is off the seat without setting the
parking-brake pedal at the braking position, the mower will automatically park on the slope using the battery power. The
auto-parking icon will ash, meanwhile the audio indicator will emit intermittent beeps.
Set the parking-brake pedal in the braking position. The auto-parking icon will be off and the audio indicator will no
longer sound.
WARNING: When the battery power is depleted, the mower can slide down the slope, which may cause
serious mower damage or personal injury!
WARNING: In case of any emergency, please engage the parking brake.
USB Icon
Illuminates to indicate that a USB device can be connected after the mower is started correctly.
Load Indicator
Indicates the current load of the mower. When the load is in the ECO range, the mower is under normal load. When
the load is in the PWR range, the mower is under heavy load. When in the CHG range, the mower is in the energy-
regeneration mode, such as when braking or driving downhill.
Fuel Gauge
Indicates the average charge capacity of the inserted batteries.
Low-Power Indicator
◾
When the available battery charge is too low, the mower will go into Limp-Home mode. The low-power indicator will
ash every second. The operator should stop working and drive to the battery charging area as soon as possible.
◾
When the battery is nearly depleted, the low-power indicator will ash every half a second.
Fault Code Indicator
The on-board computer system will take action to protect the operator and the machine when it detects an issue. When
it acts to turn off the machine or a component, it will indicate that a fault has occurred, and that fault code will be shown
on the LCD screen. Please see “FAULT CODE & MOWER STATUS INDICATOR REFERENCE” section in this manual for
reference.
Overload Indicator
When the mower is overloaded, the overload indicator will ash every second. Meanwhile, both mower status indicators
(on the front of the foot-rest area and above the LCD screen) will ash RED every second. The audio indicator will sound
once.
It is recommended that the operator should raise the deck cutting height to reduce the load of the mower when the over-
load indicator ashes.
Over-heat Icon
◾
When the battery is overheated, the over-heat icon will ash every second and the battery icon representing the
overheated battery will blink.
◾
When the mower is overheated, the over-heat icon will ash every second. Both mower status indicators (on the
front of the foot-rest area and above the LCD screen) will ash RED every second. The audio indicator will sound
once.
It is recommended that the operator should reduce the load of the mower by raising the deck cutting height or slowing
the blade/driving speed. Allow the battery pack or the mower to cool.
