56V LITHIUM-ION CORDLESS HEDGE TRIMMER16
descriPtion
KNOW YOUR HEDGE TRIMMER (Fig. 1)
The safe use of this product requires and understanding of the information on the
tool and in this operator’s manual, as well as knowledge of the project you are
attempting. Before use of this product, familiarize yourself with all operating
features and safety rules.
Hand Guard
Helps protect hand from cutting and deflect chips or other debris away from the
operator’s hands.
Front Handle
For easy control of the tool during cutting work.
Rear Handle
Ergonomic handle with overmold improves comfort and grip.
Front Switch Lever/Rear Switch Lever
The hedge trimmer can be started only if both of the switch levers (in rear and
front of the handle) are depressed simultaneously.
1
Blade
Blade Guard
Hand Guard
Front Handle
Front
Switch
Lever
Rear Handle
Battery-Release
Button
Electric
Contacts
Latch
Ejection Mechanism
Rear Switch
Lever
Mounting Slot
