56V LITHIUM-ION CORDLESS LINE TRIMMER 33

PARTS LIST

INDEX

NUMBER

PART NO. DESCRIPTION QTY

1 2823713000 Line cutting blade set 1

2 2823710000 Guard assembly 1

3 2823712000 Spool retainer assembly 1

4 3800097000 Cutting line 1

5 2823045000 Spool assembly 1

6 2823709000 Bump head assembly 1

7 2823711000 Front-assist handle assembly. 1

8 3660269000 Spring (in the bump head) 1

9 2822959000 Hexagon nut set (for bump head) 1

10 3650148000 Bump protector 1
