TO INSTALL THE SNOWDISCHARGE CHUTE ASSEMBLY
WARNING: Never operate the snow blower without the complete discharge chute in place.
1. Loosen the knob on the inner support pole and remove the bolt (Fig.5). Save the knob and bolt for reassembly.
2. Lift the snow-discharge chute assembly, align the outer support pole with the inner support pole, and then slide
the outer support pole into place (Fig. 5). Make sure that the snow-discharge chute is correctly seated on the
base (Fig.6).
3. Secure the snow discharge chute assembly with the reserved knob and bolt.
WARNING: Use the chute rotation handle to make sure that the chute rotates properly and that the discharge
