56-VOLT LITHIUM-ION CORDLESS 15" BRUSHLESS STRING TRIMMER 11
PACKING LIST
PART NAME QUANTITY
String Trimmer 1
Guard 1
Front-assist handle assembly 1
M5 Hex wench 1
Bolts for locking shaft (only available to ST1500-S) 2
Operator's manual 1
UNFOLDING THE SHAFT (ONLY AVAILABLE TO ST1500-S)
WARNING:
Do not hold the shaft at the joints in order to avoid pinching your
hands or fingers.
WARNING:
Do not attempt to start the trimmer until the shaft has been locked.
1. Remove the battery pack from the
trimmer.
2. Put your trimmer on the ground and
carefully unfold the shaft. Make sure
that the cable is inside the shaft
make sure that it will not be pinched
when closing the joints (Fig. 1).
3. Use the M5 hex wrench to lock the
shaft with two bolts (Fig. 2).
1
2
