Table 3 Ei650i Indicators explained
12.1. Normal Operation
12.1.1. Power Up
Twist the Alarm onto the base to power up, the red LED will flash once
followed by one flash of the yellow LED to indicate that the Alarm has been
powered successfully and is now in standby mode.
12.1.2. Standby
In standby mode there are no active visible or audible indications which can be
intrusive to the householder. To confirm that the Alarm is operational perform
a weekly button test.
12.1.3. Weekly button test
Press and hold the test button and verify that the red LED flashes rapidly and
the Alarm ramps up to full sound.
12.1.4. Sensing Fire
As soon as the Alarm senses smoke it will go into alarm (along with any
interconnected Alarms). The red LED on the Alarm sensing smoke flashes
rapidly to indicate it is the Alarm sensing fire. Follow the instruction in section
6 and evacuate the building.
33
