Eilersen MCE2035 - Jumpers

MCE2035: User manual
Version: 2011-05-17, rev.: 0a Page: 18
8.5 Jumpers
The Profibus-DP module is equipped with 7 jumpers. These jumpers have these functions:
JUMPER FUNCTION
JU1 Reserved for future use
(normal default factory setting is OFF)
JU2-JU4 Reserved for future use (termination)
(normal default factory setting is OFF)
JU6 Reserved for future use
(normal default factory setting is OFF)
JU7
Selection of (32 Bit Signed Integer) / (IEEE754) data format
The jumper determines if the weight indications in the telegram are in
32 bit signed integer or in IEEE754 floating point format.
OFF: 32 bit signed integer format (normal setting from factory)
ON: IEEE754 floating point format
JU8
Selection of LSB/MSB data format
The jumper determines the byte order in which data are transmit-
ted/received.
OFF: LSB first
ON: MSB first (normal setting from factory)
