9) STATUS CODES
Status codes are shown as a 4 digit hex number. If more than one error condition is present
the error codes are OR’ed together.
CODE
(Hex)
CAUSE
0001
Invalid/missing ’sample’ ID
Bad connection between communication module and load cell module.
0002
Load cell timeout
Check that the load cell is connected to the load cell module.
0004
Load cell not synchronized
Bad connection between load cell and load cell module.
0008
Hardware synchronization error
Cable between load cell modules shorted or disconnected.
0010
Power failure
Supply voltage to load cells is to low.
0020
Overflow in weight calculation
Internal error in load cell module.
0040
Invalid/missing ’latch’ ID
Bad connection between communication module and load cell module.
0080
No answer from load cell module
No data is received from this load cell module. This can be caused by the
removal of the load cell module, no power to the module or that the connec-
tion between load cell module and communication module is broken.
0100 Reserved for future use
0200 Reserved for future use
0400 Reserved for future use
0800
No load cell modules answer
Bad connection between communication module and load cell module. Not
all telegrams from communication module are received in load cell module.
1000 Reserved for future use
2000 Reserved for future use
4000 Reserved for future use
8000 Reserved for future use
