2. Technical data
Power Supply 230 V ~ 50 Hz
Power rating: 1800 W
Cutting length, max.: 40 cm
Cutting speed at rated rpm: 13,5 m/s
Oil tank capacity: 250 ml
Weight without sword + chain: 4,1 kg
Protection class: II /
쵭
Guaranteed sound power level under load: 103 dB(A)
Sound pressure level under load: 89 dB(A)
Acceleration Rear grip under load: 5,3 m/s
2
(calculated acc. to EN 50144) Front grip under load: 4,8 m/s
2
1. List of parts
1 Front finger guard
2 Front grip
3 Oil tank cover
4 Safety lock-off
5 On/Off switch
6 Rear grip
7 Mains cable
8 Cable holder
9 Chain wheel cover
10 Bar fastening nut incl. Protective cap
11 Chain bar
12 Saw chain
13 Claw stop
3. Explanation of the signs
1. Wear protective headgear, goggles and ear muffs
2. Important! Read the operating instructions and follow the warnings and safety instructions
3. If the cable is damaged, pull out the power plug immediately!
4. Protect from the damp
