Measured Sound pressure level LPA: … 76.17 dB(A)
Uncertainty KPA: … 3 dB(A)
Sound power level LWA: … 86.51 dB(A)
Uncertainty KWA: …1.26 dB(A)
Guaranteed sound power level LWA: … 96 dB(A)
Vibration at the handlebars ah: … ≤2.5 m/s2
Uncertainty K: …1.5 m/s2
Cutting height adjustment: …25-65 mm; 5 levels
Power X-Change lithium-ion batteries
Voltage: … 18 V DC
Capacity: … 4.0 Ah
Number of cells: … 10
Power X-Charger battery charger
Input voltage: …200-250 V ~ 50-60 Hz
Output voltage: …20 V DC
Output current: … 3 A
Protection class:…II /
Important!
The charger is allowed to be used only for the lithium-ion batteries of the Power X-Change series!
Keep the noise emissions and vibrations to a minimum.
Only use appliances which are in perfect working order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever necessary.
Switch the appliance off when it is not in use.
Wear protective gloves.
Residual risks
Even if you use this electric power tool in accordance with the instructions, certain residual risks cannot be
eliminated. The following hazards may arise in connection with the equipment’s construction and layout:
1. Lung damage if no suitable protective dust mask is used.
2. Damage to hearing if no suitable ear protection is applied.
Warning!
This equipment generates an electromagnetic field during operation. Under certain circumstances this field
may actively or passively impede medical implants. To reduce the risk of serious or fatal injuries, we
recommend persons with medical implants to consult their doctor and the manufacturer of the medical
implant prior to using the equipment.
5. Before starting the equipment
The lawn mower is delivered partly assembled. The push bar and the grass basket must be assembled before using
the lawn mower. Follow the instructions step by step and refer to the pictures when assembling.
Important! Required assembly parts (screws, cable guides, etc.) or functional parts (e.g. plugs, wrenches, etc.) can
be found in the molded parts of the packaging or on the equipment.
Mounting the push bar (Fig. 3 to 5)
Start by fastening the lower push bars for the left-hand side (Fig. 3/Item 10) and the right-hand side (Fig. 3/Item 11)
to the mower housing using the fastening screws (Fig. 3/Item 12,13a). The upper push bar then has to be slid onto
the lower push bars and fastened with screws (Fig. 4/Item 13,13a). There are 2 different holes on each of the lower
push bars for this, to enable the height of the push bar to be adjusted to the height of the user. Then fasten the power
