EINHELL RT-RH 20 User Manual

GB
13
 Important!
When using equipment, a few safety precautions
must be observed to avoid injuries and damage.
Please read the complete operating manual with due
care. Keep this manual in a safe place, so that the
information is available at all times. If you give the
equipment to any other person, give them these
operating instructions as well.
We accept no liability for damage or accidents which
arise due to non-observance of these instructions
and the safety information.
1. Safety regulations
The corresponding safety information can be found
in the enclosed booklet.
 CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a
safe place for future use.
2. Layout (Fig. 1)
1. Dust guard
2. Locking sleeve
3. Selector switch for drill/hammer drill/chisel
4. ON/OFF switch
5. Handle
6. Additional handle
7. Depth stop
8. Locking button
9. Clockwise/counter-clockwise switch
10. Clamping screw
11. Speed controller
3. Items supplied
Take all the parts out of the packaging.
Check that nothing is missing.
 RT-RH 20 hammer drill
 Additional handle
 Depth stop
 Operating instructions
 Safety regulations
4. Proper use
The tool is designed for drilling with hammer action in
concrete, rock and brick, as well as for chiseling
work, always using the respective correct drill or
chisel bit.
The equipment is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
5. Technical data
Mains voltage: 220-240 V ~ 50 Hz
Power input: 600 W
Idling speed: 0-1200 rpm
Blow rate: 0-5800 rpm
Drilling capacity in concrete/stone (max.): 20 mm
Protection class: II / 쓑
Weight: 2.8 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
L
pA
sound pressure level 90 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 101 dB(A)
K
WA
uncertainty 3 dB
The hammer drill is not designed for outdoors use as
specified I Article 3 of Directive
2000/14/EC_2005/88/EC.
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Total vibration values (vector sum of three directions)
determined in accordance with EN 60745.
Anleitung_RT_RH_20_SPK7:_ 16.03.2010 9:24 Uhr Seite 13

EINHELL RT-RH 20 Specifications

General

Cord length	3 m
Input power	600 W
Power source	AC
AC input voltage	220-240 V
AC input frequency	50 Hz
Impact rate	5800 bpm
Rated speed (max)	1200 RPM
Impact energy (max)	1.8 J
Drilling diameter in steel (max)	- mm
Drilling diameter in concrete (max)	20 mm
Reverse	Yes
Chuck type	SDS Plus
Product color	Black, Red

Weight and Dimensions

Depth	380 mm
Width	118 mm
Height	365 mm
Weight	2800 g
