Harmful emissions of wood dust when the
machine is used in closed rooms.
The machine is to be used only for its prescribed
purpose. Any other use is deemed to be a case of
misuse. The user / operator and not the
manufacturer will be liable for any damage or injuries
of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
5. Technical data
Voltage 230V-240V ~ 50 Hz
Power rating 900 W
Idle speed n
0
4800 rpm
Carbide saw blade Ø 205 x Ø 16 x 2.6 mm
Number of teeth 24
Table size 525 x 400 mm
Cutting height max.90° 45 mm
Cutting height max.45° 42 mm
Connector for dust extractor dia. 36 mm
Safety insulated II / 쏾
Weight 14 kg
Sound and vibration
Sound and vibration values were measured in
accordance with EN 61029.
L
pA
sound pressure level 93,9 dB(A)
K
pA
uncertainty 3 dB
L
WA
sound power level 106,8 dB(A)
K
WA
uncertainty 3 dB
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Keep the noise emissions and vibrations to a
minimum.
Only use appliances which are in perfect working
order.
Service and clean the appliance regularly.
Adapt your working style to suit the appliance.
Do not overload the appliance.
Have the appliance serviced whenever
necessary.
Switch the appliance off when it is not in use.
6. Before putting the machine into
operation
Make sure the machine stands securely, i.e. bolt
it to a workbench or solid base.
All the covers and safety devices have to be
properly fitted before the machine is switched on.
It must be possible for the saw blade to run
freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machine’s moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
7. Assembly
Important. Always pull out the power plug before
carrying out any maintenance or conversion
work on the bench type circular saw.
7.1 Fitting the saw blade (Fig. 2/3)
Important! Pull out the power plug.
Loosen the chip bin cover (19) by undoing the
fixing screws (20) and swing it up.
Undo the nut with a ring wrench (30) on the nut
itself and a second wrench (31) on the motor
shaft (32) to apply counter-pressure.
Important! Turn the nut in the direction of
rotation of the saw blade (4).
Take off the outer flange and pull the old saw
blade (4) off the inner flange by dropping the
blade at an angle.
Clean the mounting flange.
Fit the new saw blade in reverse order.
Important! Note the direction of rotation (see
arrow on the saw blade).
7.2 Adjusting the splitter (Fig. 4/5/6)
Remove the saw blade guard (2) (see 7.3).
Take out the table insert (6) (see 7.4).
Slacken the two hexagon socket-head screws
(24).
