2. Layout and items supplied
2.1 Layout (Fig. 1-3)
1 Tank cover
2 Carry handle
3 Safety tripping element
4 Choke lever
5 ON/OFF switch
6 230 V ~ socket
7 Reversing starter
8 Petrol cock
9 Spark plug wrench
2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the
operating instructions.
• O pen the packaging and take out the
equipment with care.
R emove the packaging material and any
packaging and/or transportation braces (if
available).
• C heck to see if all items are supplied.
• I nspect the equipment and accessories for
transport damage.
• I f possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger
of swallowing or suff ocating!
• Original operating instructions
3. Proper use
T he device is designed for applications operated
with a 230 V alternating current source. Be sure
to observe the restrictions in the safety
instructions. The generator is intended to provide
electric tools and light sources with electricity.
When using the device with household
appliances, please check their suitability in
accordance with the relevant manufacturer’s
instructions. In case of doubt, ask an authorized
dealer of the respective appliance.
The equipment is to be used only for its
prescribed purpose. Any other use is deemed to
be a case of misuse. The user / operator and not
the manufacturer will be liable for any damage or
injuries of any kind caused as a result of this.
Please note that our equipment has not been
designed for use in commercial, trade or
industrial applications. Our warranty will be
voided if the machine is used in commercial,
trade or industrial businesses or for equivalent
purposes.
4. Technical data
G enerator .......................................
Synchronous Protection type:
........................................IP 23M Continuous
rated power P
rated
(S1): ............ 680 W
Maximum power P
max
(S2 5 min): ............... 700 W
Maximum power P
max
(1 min): .................... 800 W
Rated voltage: ......................................... 230 V~
Rated current: .........................................2.96 A~
Frequency: .................................................50 Hz
Drive engine design ..............2-stroke, air-cooled
Displacement ........................................ 63.5 cm
3
Max. power: ................................1 kW / (1.36 PS)
Fuel: .................................................Mixture 1:40
Tank capacity: ..................................................4
l Consumption at 3/4 load ................approx. 0,6
l/h
Weight: .....................................................16.5 kg
Sound pressure level LpA: ................. 68.5 dB(A)
LWA sound power level/KWA uncertainty
................................................ 90 dB(A) / 2 dB(A)
Spark plug: ......................................... LG
F6RTC
Operating mode S1 (continuous operation)
The machine can be continuously operated with
the quoted power output.
Operating mode S2 (temporary operation) The
machine may be temporarily operated with the
quoted power output. Afterwards the machine
must be stopped for a while to prevent it from
overheating.
