EINHELL TC-PG 10/E5 User Manual

GB
•
Anl_TC_PG_10-E5_SPK9.indb 22 07.11.2019 10:00:22
Clean the filter element with soapy water,
rinse with clear water and leave to dry well
before re-installing.
• Assemble in reverse order
7.3. Spark plug (Fig. 7) Check the spark plug
for dirt and grime after 10 hours of operation
and if necessary clean with a copper wire
brush. Thereafter service the spark plug after
every 50 hours of operation. • Pull off the
spark plug boot with a twist.
• Remove the spark plug with the supplied
spark plug wrench.
• Assemble in reverse order 7.4 Maintenance
• There are no parts inside the equipment
which require additional maintenance.
7.5 Storage
Notice! If you fail to follow these instructions
correctly, deposits may form on the interior of the
carburetor which may result in the engine being
more diffi cult to start or the machine suff ering
permanent damage.
1. Carry out all the maintenance work.
2. Drain the fuel out of the tank (use a
conventional plastic petrol pump from a DIY
store for this purpose).
3. When the fuel has been drained, start the
engine.
4. Allow the engine to run at idling speed until it
stops. This will clean the remainder of the
fuel out of the carburetor.
5. Leave the machine to cool (approx. 5
minutes).
6. Remove the spark plug (see point 7.3).
7. Clean the exterior housing of the machine.
8. Store the machine in a cold, dry place where
it is out of the reach of ignition sources and
infl ammable substances.
Restarting 1. Remove the
spark plug.
2. Pull the starter cable several times to clean
the oil residue out of the combustion
chamber.
3. Clean the spark plug contacts or fi t a new
spark plug.
4. Fill the tank.
Transport
To transport the machine, fi rst empty the petrol
tank as described in section 2 in the section
entitled “Storage”. Clean coarse dirt off the
machine with a brush or hand brush. 7.6
Ordering replacement parts: Please quote the
following data when ordering replacement parts:
• T ype of machine
• A rticle number of the machine
• I dentification number of the machine
• R eplacement part number of the part
required For our latest prices and information
please go to isc-gmbh.info
8. Disposal and recycling
The equipment is supplied in packaging to
prevent it from being damaged in transit. The raw
materials in this packaging can be reused or
recycled. The equipment and its accessories are
made of various types of material, such as metal
and plastic. Never place defective equipment in
your household refuse. The equipment should be
taken to a suitable collection center for proper
disposal. If you do not know the whereabouts of
such a collection point, you should ask in your
local council offi ces.
9. Transportation
• Use the handle for transporting the generator
and use it to move the generator about.
• Transport the equipment only by carrying it
by the transport handle.
• Protect the equipment against unexpected
knocks and vibrations.
- 20
-
10. T roubleshooting
Fault
Possible cause
Remedy

EINHELL TC-PG 10/E5 Specifications

General

Fuel type	Gasoline
Motor type	Synchronous motor
Noise level	- dB
Rated power	- W
Cooling type	Air
Maximum power	1000 W
Rated voltage	- V
Engine speed (max)	3000 RPM
Fuel tank capacity	4 L
AC outlets quantity	1 AC outlet(s)
Engine displacement	63.5 cm³
Number of cylinders	1
Running time @ 2/3 load	6.6 h
Engine number of strokes	2
Castor wheels	-
Product color	Black, Red

Weight and Dimensions

Weight	18800 g
Package depth	430 mm
Package width	353 mm
Package height	365 mm
Package weight	20300 g
