EINHELL TC-PW 340 User Manual

GB
- 14 -
Danger!
When using the equipment, a few safety pre-
cautions must be observed to avoid injuries and
damage. Please read the complete operating
instructions and safety regulations with due care.
Keep this manual in a safe place, so that the in-
formation is available at all times. If you give the
equipment to any other person, hand over these
operating instructions and safety regulations as
well. We cannot accept any liability for damage
or accidents which arise due to a failure to follow
these instructions and the safety instructions.
1. Safety regulations
The corresponding safety information can be
found in the enclosed booklet.
Danger!
Read all safety regulations and instructions.
Any errors made in following the safety regula-
tions and instructions may result in an electric
shock, re and/or serious injury.
Keep all safety regulations and instructions
in a safe place for future use.
Protect yourself and your environment from risks
and accidents by taking the appropriate precauti-
onary measures.
2. Layout and items supplied
2.1 Layout (Fig. 1-4)
1. Trigger lever
2. Switch for setting forward/reverse rotation
and the torque
3. Square driver mount for connector
4. Nipple
5. Oil bottle (without oil)
6. Plug-on attachments (sizes: 8 mm, 10 mm, 11
mm, 13 mm, 17 mm, 19 mm, 21 mm, 22 mm)
2.2 Items supplied
Please check that the article is complete as
specied in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suocating!
•
Pneumatic impact driver
•
Nipple
•
Oil bottle (without oil)
•
Plug-on attachments (8 items)
•
Original operating instructions
•
Safety information
3. Proper use
The impact driver is a handy, pneumatically
operated tool designed for DIY applications. It
is suitable for fastening and releasing threaded
connections.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
Remember.
Too small a diameter of the hose and too
long a hose line will result in loss of power.
Anl_TC_PW_340_SPK9.indb 14Anl_TC_PW_340_SPK9.indb 14 17.05.2022 10:27:0817.05.2022 10:27:08

EINHELL TC-PW 340 Specifications

General

Power source	Compressed air
Drive size	- \
Torque (max)	340 N⋅m
Maximum airflow	142 l/min
Idle speed (max)	7500 RPM
Maximum operating pressure	6.3 bar
Reverse	Yes
Product type	Air ratchet wrench
Product color	Black, Red
Built-in light	-

Weight and Dimensions

Depth	346 mm
Width	82 mm
Height	255 mm
Weight	1900 g
Package weight	3600 g
