3. Proper use
The tool is designed for drilling with hammer ac-
tion in concrete, rock and brick, as well as for chi-
seling work, always using the respective correct
drill or chisel bit.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
4. Technical data
See warranty card of your country.
The rotary hammer is not designed for outdoors
use as specied I Article 3 of Directive 2000/14/
EC_2005/88/EC.
Wear ear-mus.
The impact of noise can cause damage to hea-
ring.
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
Before you connect the equipment to the mains
supply make sure that the data on the rating plate
are identical to the mains data.
Warning!
Always pull the power plug before making
adjustments to the equipment.
Check the drilling point for concealed electrical
cables, gas and water pipes using a cable/pipe
detector.
5.1 Additional handle (Fig. 2 – Item 6)
For safety reasons you must only use the
hammer drill with the additional handle.
The additional handle (6) enables you to achieve
better stability whilst using the rotary hammer.
The machine must not be used without the additi-
onal handle (6) for safety reasons.
The additional handle (6) is secured to the rotary
hammer by a clamp. Turning the handle anti-
clockwise (looking from the handle) will release
the clamp. Turning the handle clockwise will tigh-
ten the clamp.
First release the additional handle clamp. You can
then swing the additional handle (6) into the most
comfortable working position for you. Now turn
the additional handle in the opposite direction
again until the additional handle is secure.
5.2 Fitting and adjusting the depth stop
(Fig. 3/Item 7)
The depth stop (7) is held in place by the additi-
onal handle (6) by clamping. The clamp can be
released and tightened by turning the handle.
•
Release the clamp and fit the depth stop (7)
in the recess provided for it in the additional
handle.
•
Set the depth stop (7) to the same level as
the drill bit.
•
Pull the depth stop back by the required dril-
ling depth.
•
Turn the handle on the additional handle (6)
until it is secure.
•
Now drill the hole until the depth stop (7)
tou-ches the workpiece.
5.3. Tool insertion (Fig. 4)
•
Clean the tool before insertion and apply a
thin coating of drill bit grease to the shaft of
the tool.
•
Insert the dust-free tool into the tool mounting
as far as it will go whilst turning it. The tool will
lock itself.
•
Check that it is properly secure by pulling the
tool.
5.4 Tool removal (Fig. 5)
Pull back and hold the locking sleeve (2) and re-
move the tool.
6. Operation
Danger
To prevent all danger, the machine must only be
held using the two handles (6/8). Otherwise there
may be a risk of suering an electric shock if you
drill into cables.
6.1 ON/OFF switch (Fig. 6/Item 4)
•
First fit a suitable drill bit into the tool
(see 5.3).
•
Connect the mains plug to a suitable socket.
•
Position the drill in the position you wish to
drill.
To switch on:
Press the ON/OFF switch (4)
Continuous operation:
Secure the ON/OFF switch (4) with the locking
button (5).
To switch o:
Press the ON/OFF switch (4) briey.
6.2 Adjusting the speed (Fig. 6/Item 4)
•
You can infinitely vary the speed whilst using
the tool.
•
Select the speed by applying a greater or les-
ser pressure to the ON/OFF switch (4).
•
Select the correct speed: The most suitable
speed depends on the workpiece, the type of
use and the drill bit used.
•
Low pressure on the ON/OFF switch (4): Lo-
wer speed
•
Greater pressure on the ON/OFF switch (4):
Higher speed
•
Tip: Start drilling holes at low speed. Then
increase the speed in stages.
Anl_SA_TC_RH_800_4F_SPK8.indb 26Anl_SA_TC_RH_800_4F_SPK8.indb 26 31.05.2021 09:52:3731.05.2021 09:52:37

EINHELL TC-RH 800 4F Specifications

General

Reverse	-
Drilling	Yes
Chuck type	SDS Plus
Product color	Black, Red
Power protection features	Overload
Input power	800 W
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 Hz
Idle speed (max)	4500 RPM
Rated speed (max)	930 RPM
Rated speed (min)	0 RPM
Impact energy (max)	2.6 J
Drilling diameter in concrete (max)	26 mm

Weight and Dimensions

Weight	3120 g
Package weight	4970 g
